UNS S30900 - EN 1.4828

Name: UNS S30900 - EN 1.4828
Brand: Ninesteel
Price: 100.0 USD
Availability: InStock

Product variants

EN 1.4828 plates are renowned for excellent corrosion resistance and superior creep strength. Additionally, the stainless steel boasts significant tensile strength, accuracy of dimensions, durability, machinability, formability, weldability, and ductility.

Equivalent grades

• UNS S30900
• DIN 1.4828
• AISI 309
• X15CrNiSi20-12

Chemical Composition Reference

0.04C-20Cr-12Ni-2Si

Physical Property Reference

• Density: 7.8 g/cc

• Tensile Strength: 610 MPa

• Yield Strength: 270 MPa

• Modulus of Elasticity: 196 GPa

• Thermal Conductivity: 12.6 W/m-K

Stock & Dimensions

Our warehouse has a large number of stock to provide you with a variety of products in different sizes, and can also customize the size according to your needs.
• Bar: 0.5~600mm Diameter
• Coil: 0.5~150mm Thick
• Plate: 0.5~200mm Thick
• Pipe: 6~630mm External Diameter; 0.5~40mm Wall Tick
• Available in specific sizes

Product Forms

We provide you with a variety of product forms, including but not limited to:
• Bar/Rod
• Pipe/Tube
• Coil/Strip
• Plate/Sheet/Circle
• Wire
• Fitting (Flange, Elbow, Tee...)
• Customize

View full details

UNS S30900 - EN 1.4828

Essential details

AISI 309/1.4828 is a heat resistant austenitic chromium-nickel-stainless steel. It is a popular stainless steel in the field of furnace construction and high-temperature components, due to its scale resistance. Up to a maximum temperature of 1000°C in air, this heat-resistant austenitic stainless steel offers excellent resistance to corrosion, oxidation and carburization.

Application:

- Furnace and apparatus engineering

- Components of industrial furnaces and boilers

- Piping and compensators

- Electric heating elements

- Aeronautical engineering

- Car exhaust systems
