Nimonic 101

Name: Nimonic 101
Brand: Ninesteel
Availability: InStock

Product variants

Nimonic 101 is enhanced with a greater chromium presence, enabling it to endure considerable resistance to heat corrosion when exposed to sulfur or salt-containing atmospheres. Its resistance to heat corrosion makes Nimonic 101 a reliable solution for a variety of industrial applications, including marine and aircraft engines.

Equivalent grades

• Nimonic 101
• Alloy 101
• UNS N13021

Chemical Composition Reference

24.2Cr-19.7Co-3Ti-1.5Mo-1.4Al-1Nb-0.05Zr-0.012B-0.01C

Physical Property Reference

• Density: 7.7-8.03 g/cm³

• Tensile strength: 1158 MPa

• Yield strength: 1034 MPa

• Elastic modulus: 190-210 GPa

• Elongation at break:15%

Stock & Dimensions

Our warehouse has a large number of stock to provide you with a variety of products in different sizes, and can also customize the size according to your needs.
• Bar: 0.5~600mm Diameter
• Coil: 0.5~150mm Thick
• Plate: 0.5~200mm Thick
• Pipe: 6~630mm External Diameter; 0.5~40mm Wall Tick
• Available in specific sizes

Product Forms

We provide you with a variety of product forms, including but not limited to:
• Bar/Rod
• Pipe/Tube
• Coil/Strip
• Plate/Sheet/Circle
• Wire
• Fitting (Flange, Elbow, Tee...)
• Customize

View full details

Nimonic 101

Essential details

Nimonic 101 is one of the early nickel-based superalloys developed for the use in gas turbines. In such environments, the material is exposed to a combination of both high temperatures and mechanical loads for a long duration.

Applications:

Nimonic 101™ is mainly used in gas turbine hot section components, e.g. turbine blades, which are required in marine environments or where low grade sulfur-containing fuels are burnt.
