Monel K500

Monel K500

Monel K500 boasts enhanced strength and hardness over Monel 400, along with superior corrosion resistance. It offers excellent mechanical properties and a high resistance to a variety of corrosive environments. Plus, it's resistant to stress-corrosion cracking and has good pitting resistance in many media.

Equivalent grades

• Monel K500
• UNS N05500
• W.Nr. 2.4375

Chemical Composition Reference


Physical Property Reference

• Density: 8.45 g/cm³

• Melting Point: 1338°C

• Tensile Strength: 1000 MPa

• Yield Strength: 655 MPa

• Elongation at break: 22%

• Reduction of Area: 40%

• Hardness, Rockwell C: 27

Stock & Dimensions

Our warehouse has a large number of stock to provide you with a variety of products in different sizes, and can also customize the size according to your needs.
• Bar: 0.5~600mm Diameter
• Coil: 0.5~150mm Thick
• Plate: 0.5~200mm Thick
• Pipe: 6~630mm External Diameter; 0.5~40mm Wall Tick
• Available in specific sizes

Product Forms

We provide you with a variety of product forms, including but not limited to:
• Bar/Rod
• Pipe/Tube
• Coil/Strip
• Plate/Sheet/Circle
• Wire
• Fitting (Flange, Elbow, Tee...)
• Customize

View full details

Monel K500

Essential details
Monel K500 material is a nickel-copper alloy that combines the excellent corrosion resistance characteristic of Monel 400 with the added advantage of greater strength and hardness. These amplified properties, strength and hardness, are obtained by adding aluminum and titanium to the nickel-copper base and by a thermal processing used to effect precipitation, typically called age hardening or aging.

When in the age-hardened condition, Monel K-500 has a greater tendency toward stress-corrosion cracking in some environments than Monel 400. Alloy K-500 has approximately three times the yield strength and double the tensile strength when compared with alloy 400.

Plus, it can be further strengthened by cold working prior to precipitation hardening. The strength of this nickel steel alloy is maintained to 1200° F but stays ductile and tough down to temperatures of 400° F. Its melting range is 2400-2460° F.


- Valve trim

- Sour-gas service applications

- Oil and gas production safety lifts and valves

- Oil-well tools and instruments like drill collars

- Doctor blades and scrapers

- Pump shafts and impellers in marine service

- Sensors and Electronic components

- Liquid Rocket Engine Components

- LOX Manifolds and Injectors

- Chains, cables, springs, valve trim, fasteners for marine service.
