ASTM 436 - EN 1.4513

ASTM 436 - EN 1.4513

ASTM 436 and EN 1.4513 are molybdenum modified, heat-resistant ferritic stainless steels. They offer improved ductility and a greater ability to withstand mechanical stresses at elevated temperatures. These steels are ideal for use in elevated-temperature applications such as automotive components.

Equivalent grades

• AISI/ASTM 436
• DIN 1.4513
• UNS S43600
• X2CrMoTi17-1

Chemical Composition Reference

16.0 – 18.0Cr, 0.9

Physical Property Reference

• Density: 7.7 g/cm³

• Electrical resistance: 0.60 μΩ·m

• Thermal conductivity: 23 W/(m·K)

• Specific heat: 460 J/(kg·K)

• Young's modulus: 220 GPa

• 0.2% Yield stress: 240 MPa, min

Stock & Dimensions

Our warehouse has a large number of stock to provide you with a variety of products in different sizes, and can also customize the size according to your needs.
• Bar: 0.5~600mm Diameter
• Coil: 0.5~150mm Thick
• Plate: 0.5~200mm Thick
• Pipe: 6~630mm External Diameter; 0.5~40mm Wall Tick
• Available in specific sizes

Product Forms

We provide you with a variety of product forms, including but not limited to:
• Bar/Rod
• Pipe/Tube
• Coil/Strip
• Plate/Sheet/Circle
• Wire
• Fitting (Flange, Elbow, Tee...)
• Customize

INQUIRY NOW
View full details

ASTM 436 - EN 1.4513

Essential details
AISI/ASTM 436: Excellent general corrosion resistance (under conditions typical of car exhaust systems), i.e. against pitting corrosion (comparable to 1.4301), stress corrosion cracking and intergranular corrosion as well as oxidation (up to 850 °C); good formability and weldability; low coefficient of thermal expansion; high thermal conductivity (resulting in an even appearance)

Application:

- Heat exchangers

- Acid and nitrogen oxide pipelines

- Acid storage tanks

- Acid transport tanks

- Dairy, fruit and vegetable and brewery industries

- Textile industry

- Household appliances
