ASTM 434 - EN 1.4113

ASTM 434 - EN 1.4113

ASTM 434 - EN 1.4113 is a ferritic stainless steel developed for fabrication into finished products. This material has been certified for its annealed condition properties. According to EN standards, it is designated by numeric identifier 1.4113 and its chemical composition is X6CrMo17-1.

Equivalent grades

• DIN 1.4113
• UNS S43400
• X6CrMo17-1

Chemical Composition Reference

16.0 – 18.0Cr, 0.9

Physical Property Reference

• Density: 7.7 g/cm³

• Electrical resistance: 0.60 μΩ·m

• Thermal conductivity: 23 W/(m·K)

• Specific heat: 460 J/(kg·K)

• Young's modulus: 220 GPa

• 0.2% Yield stress: 240 MPa, min

Stock & Dimensions

Our warehouse has a large number of stock to provide you with a variety of products in different sizes, and can also customize the size according to your needs.
• Bar: 0.5~600mm Diameter
• Coil: 0.5~150mm Thick
• Plate: 0.5~200mm Thick
• Pipe: 6~630mm External Diameter; 0.5~40mm Wall Tick
• Available in specific sizes

Product Forms

We provide you with a variety of product forms, including but not limited to:
• Bar/Rod
• Pipe/Tube
• Coil/Strip
• Plate/Sheet/Circle
• Wire
• Fitting (Flange, Elbow, Tee...)
• Customize

View full details

ASTM 434 - EN 1.4113

Essential details
ASTM 434 - EN 1.4113, similar to X6CrMoS17-1, is a stainless steel with excellent soft magnetic properties. Its high molybdenum and its low sulphur content provide a very good corrosion resistance in water, steam and other moderate aggressive media. It provides also a higher resistance against pitting corrosion.

This Steel is mainly used in solenoid valves for pneumatic and hydraulic applications with higher requirements regarding corrosion resistance like in medical equipment.


- Heat exchangers

- Acid and nitrogen oxide pipelines

- Acid storage tanks

- Acid transport tanks

- Dairy, fruit and vegetable and brewery industries

- Textile industry

- Household appliances
