ASTM 405 - EN 1.4002

ASTM 405 - EN 1.4002

EN 1.4002 stainless steel, with the chemical designation X6CrAl13, is specifically formulated for forming into wrought products. Ideal for its annealed properties, 1.4002 is the EN assigned designation.

Equivalent grades

• DIN 1.4002
• UNS S40500
• X6CrAl13
• 04Cr13

Chemical Composition Reference

12.0 – 14.0Cr

Physical Property Reference

• Density: 7.7 g/cm³

• Modulus of Elasticity: 190-210 GPa

• Thermal conductivity: 24.9 W/(m·K)

Stock & Dimensions

Our warehouse has a large number of stock to provide you with a variety of products in different sizes, and can also customize the size according to your needs.
• Bar: 0.5~600mm Diameter
• Coil: 0.5~150mm Thick
• Plate: 0.5~200mm Thick
• Pipe: 6~630mm External Diameter; 0.5~40mm Wall Tick
• Available in specific sizes

Product Forms

We provide you with a variety of product forms, including but not limited to:
• Bar/Rod
• Pipe/Tube
• Coil/Strip
• Plate/Sheet/Circle
• Wire
• Fitting (Flange, Elbow, Tee...)
• Customize

View full details

ASTM 405 - EN 1.4002

Essential details
ASTM 405 - EN 1.4002 has a fairly high thermal conductivity among wrought ferritic stainless steels. In addition, it has a fairly low embodied energy and a moderately low base cost.


- Heat exchangers

- Acid and nitrogen oxide pipelines

- Acid storage tanks

- Acid transport tanks

- Dairy, fruit and vegetable and brewery industries

- Textile industry

- Household appliances
