ASTM 321 - EN 1.4541

Name: ASTM 321 - EN 1.4541
Brand: Ninesteel
Price: 100.0 USD
Availability: InStock

Product variants

321 stainless steel strip is a Ni-Cr-Mo austenitic stainless steel alloy. Characterized by increased corrosion resistance at the grain boundaries and improved high temperature strength, 321 effectively suppresses the formation of chromium carbides. In addition, it offers good resistance to atmospheric corrosion.

Equivalent grades

• ASTM 321
• DIN 1.4541
• UNS S32100
• X6CrNiTi18-10

Chemical Composition Reference

0.04C-17.3Cr-9.1Ni-Ti

Physical Property Reference

• Density: 7.90 g/cc

• Tensile Strength: 570 MPa

• Yield Strength: 200 MPa

• Modulus of Elasticity: 200 GPa

• Specific Heat Capacity: 0.500 J/g-°C

Stock & Dimensions

Our warehouse has a large number of stock to provide you with a variety of products in different sizes, and can also customize the size according to your needs.
• Bar: 0.5~600mm Diameter
• Coil: 0.5~150mm Thick
• Plate: 0.5~200mm Thick
• Pipe: 6~630mm External Diameter; 0.5~40mm Wall Tick
• Available in specific sizes

Product Forms

We provide you with a variety of product forms, including but not limited to:
• Bar/Rod
• Pipe/Tube
• Coil/Strip
• Plate/Sheet/Circle
• Wire
• Fitting (Flange, Elbow, Tee...)
• Customize

View full details

ASTM 321 - EN 1.4541

Essential details

321/4541 is a titanium-stabilized austenitic stainless steel with improved intergranular corrosion resistance for an extended temperature range. 321/4541 is an austenitic stainless steel that belongs to the standard CrNi stainless steel family. 321/4541 can be welded in all dimensions without becoming susceptible to intergranular corrosion.

The austenitic CrNi standard grades are the most widely used group of stainless steels. Their well-balanced material properties make them suitable for the fabrication of many products. Due to its titanium content, 321/4541 can be used at elevated temperatures. For high-temperature applications, the use of the optimized high-temperature Therma 321H/4878 is recommended.

321/4541 is available in many product forms and dimensions, often also from many stainless steel stockholders. Polishing of 321/4541 is limited due to its titanium alloying.

Typical Applications:

- Annealing covers

- Stack liners

- Automotive exhaust systems

- Welded pressure vessels

- Flanges and valves
