ASTM 316Ti - EN 1.4571

ASTM 316Ti - EN 1.4571

316Ti stainless steel has a titanium content of roughly 0.5%. Titanium strengthens and stabilises the structure of 316Ti at high temperatures of over 800°C, protecting it from corrosion caused by carbide precipitation on the grain boundaries.

Equivalent grades

• ASTM 316Ti
• DIN 1.4571
• UNS S31635
• X6CrNiMoTi17-12-2

Chemical Composition Reference


Physical Property Reference

• Density: 8.0 g/cm³

• Tensile Strength: 570 MPa

• Yield Strength: 220 MPa

• Melting Point: 1400 °C

• Thermal Expansion: 15.9 x10^-6 /K

• Modulus of Elasticity: 193 GPa

• Thermal Conductivity: 16.3 W/m.K

Stock & Dimensions

Our warehouse has a large number of stock to provide you with a variety of products in different sizes, and can also customize the size according to your needs.
• Bar: 0.5~600mm Diameter
• Coil: 0.5~150mm Thick
• Plate: 0.5~200mm Thick
• Pipe: 6~630mm External Diameter; 0.5~40mm Wall Tick
• Available in specific sizes

Product Forms

We provide you with a variety of product forms, including but not limited to:
• Bar/Rod
• Pipe/Tube
• Coil/Strip
• Plate/Sheet/Circle
• Wire
• Fitting (Flange, Elbow, Tee...)
• Customize

View full details

ASTM 316Ti - EN 1.4571

Essential details
Stainless steel types 1.4401 and 1.4404 are also known as grades 316 and 316L respectively. Grade 316 is an austenitic grade second only to 304 in commercial importance.

316 stainless steel contains an addition of molybdenum that gives it improved corrosion resistance. This is particularly apparent for pitting and crevice corrosion in chloride environments.

316L, the low carbon version of 316 stainless steel, is immune to grain boundary carbide precipitation (sensitisation). This makes it suited to use in heavy gauge (over about 6mm) welded components. For elevated temperature applications the high carbon variant, 316H stainless steel and the stabilised grade 316Ti stainless steel should be employed.

Stainless steel grade 316Ti contains a small amount of titanium. Titanium content is typically only around 0.5%. The titanium atoms stabilise the structure of the 316 at temperatures over 800°C. This prevents carbide precipitation at the grain boundaries and protects the metal from corrosion. The main advantage of 316Ti is that it can be held at higher temperatures for a longer period without sensitisation (precipitation) occurring. 316Ti retains physical and mechanical properties similar to standard grades of 316.


- Food processing equipment

- Brewery equipment

- Chemical and petrochemical equipment

- Laboratory benches & equipment

- Coastal architectural panelling

- Coastal balustrading

- Boat fittings

- Chemical transportation containers

- Heat exchangers

- Mining screens

- Nuts and bolts

- Springs

- Medical implants
